Industrial plant equipment design sits at the intersection of structural engineering, mechanical design, and safety standards — getting any one of these wrong creates equipment that either fails structurally, jams in operation, or injures the people who work around it.
Most mechanical engineers working in manufacturing or industrial sectors will at some point design or specify conveyors, structural frames, or machine guarding systems. These tasks draw on different knowledge domains than precision machine design: structural steel selection, conveyor system design, and machinery safety standards (ISO 13857, ISO 14120) are not typically covered in academic curricula but are essential for practical plant engineering work. This guide provides a foundational overview of each area.
Belt Conveyor Fundamentals
Belt conveyors are the most versatile material handling system in industrial plants. Understanding the component functions helps you specify, troubleshoot, and modify conveyor systems effectively.
Belt: The carrying surface and tensile member. Specified by width (mm), carcass construction (fabric plies or steel cord for long center distances), top cover grade (general purpose, oil-resistant, heat-resistant, cut-resistant per ISO 14890), and belt rating (maximum tension per unit width, kN/m). Standard belt widths: 400, 500, 650, 800, 1000, 1200, 1400, 1600 mm. Belt tension must be calculated from the conveying load, incline, friction, and system geometry.
Drive pulley: Transmits torque from the motor to the belt via friction. Pulley face may be bare steel (for light-duty or well-tensioned systems) or rubber-lagged (diamond groove lagging for wet conditions, herringbone for bulk materials) to increase coefficient of friction and reduce slip. Drive pulley diameter should be appropriate for the belt carcass — minimum drive pulley diameter is specified by the belt manufacturer (typically 315–800 mm for fabric belt, 800–1600 mm for steel cord belt).
Tail pulley: The non-driven end pulley that redirects the belt. Typically smaller diameter than the drive pulley. The tail pulley end is where belt sag and tension changes are most critical.
Idlers (carrying and return): Support the loaded belt between pulleys. Carrying idlers typically use a 3-roll trough configuration (35° or 45° trough angle) for loose bulk materials, or flat configuration for packaged goods. Idler spacing is determined by belt sag limits and idler load rating. Typical carrying idler spacing: 1.0–1.5 m for bulk materials, 0.5–1.0 m for heavy unit loads. Return idlers support the empty return belt: flat single-roll or V-return configuration.
Take-up device: Maintains belt tension by compensating for belt stretch. Screw take-up (for short, light-duty conveyors): adjusts tail pulley position manually. Gravity take-up (for longer, heavier conveyors): a weighted carriage maintains constant tension automatically. Insufficient belt tension causes slip at the drive pulley; excessive tension reduces belt and bearing life.
Drive system: Motor, gearbox, and belt/chain final drive or direct-coupled arrangement. Conveyor drives are sized for the effective belt pull at the drive pulley, accounting for load, incline, acceleration, and friction. Variable frequency drives (VFDs) provide soft start, speed control, and energy savings for variable-throughput conveyors.
Structural Frame Member Selection
Plant equipment frames are typically fabricated from hot-rolled structural steel: angle, channel, I-beam (H-section), hollow sections (RHS, SHS, CHS), and flat plate. Material grade: structural steel S235JR (JIS SS400, ASTM A36) for general applications; S355J2 (JIS SM490) where higher strength is needed to reduce section size.
Member selection follows from the load case. For beams (bending): select the section with adequate section modulus (S = M/σ_allow). For columns (compression): check buckling using Euler’s formula or relevant standard (Appendix to AS 4100, EN 1993 or AISC 360). For tubular members in trusses (combined axial and bending): hollow sections (RHS/CHS) are preferred for their high torsional stiffness and resistance to lateral buckling.
Practical member selection for light industrial frames (1–5 tonne capacity):
• Column members: 100×100×6 SHS or 150×100×6 RHS for 2–4 m column heights with moderate loading
• Beam members: 150×75×6 RHS or 200UB (UB = Universal Beam, JIS H-beam equivalent) for 2–4 m spans under 500 kg/m distributed load
• Welded joints: full penetration butt welds for tension-critical joints; fillet welds (6–8 mm throat) for shear joints. Comply with EN ISO 5817 or AWS D1.1 for weld quality classification
Frame deflection limits: for conveyor support frames, limit deflection to L/500–L/750 of span under full load to prevent belt misalignment and idler misalignment that causes belt drift.
Machine Guarding Requirements
Machine guarding is mandated by machinery safety regulations (EU Machinery Directive 2006/42/EC, UK PSSR, US OSHA 29 CFR 1910.217) and designed to the technical requirements of ISO 13857 (Safety distances) and ISO 14120 (Guards — general requirements). Understanding the standards helps you design guards that are compliant, practical, and maintainable.
ISO 13857: Safety Distances to Hazard Zones
ISO 13857 specifies minimum safety distances from the outer edge of a guard opening to the hazardous zone, based on the opening size and the body part that could reach through it. Key reach-distance rules:
• Square opening ≤ 4 mm: hazard zone must be ≥ 2 mm away (fingertip reach)
• Square opening ≤ 8 mm: hazard zone ≥ 10 mm away
• Square opening ≤ 120 mm (hand reach through): hazard zone ≥ 850 mm away (full arm reach)
• Over-guard reach (reaching over a fixed guard): for a guard height of 1400 mm, the hazard zone must be ≥ 1800 mm from the floor level (full upward reach distance table in ISO 13857 Table 1)
These distances determine guard aperture size and guard height. Do not specify guard mesh aperture or guard height without consulting ISO 13857 for the specific hazard geometry.
ISO 14120: Guards — Design and Construction
ISO 14120 specifies construction requirements for fixed and movable guards:
• Guards must be robust — resistant to foreseeable forces including impacts from ejected parts and normal maintenance activities
• Guards must not create additional hazards (sharp edges, pinch points, trip hazards on guard feet)
• Fixed guards must require a tool for removal — they must not be openable by hand. Hex bolt fastening (not quarter-turn or thumb screws) is the standard practice
• Movable guards (access doors, interlocked panels) connected to interlocks per ISO 14119 must fail safe — loss of power must cause the guard to remain closed or the machine to stop
• Guard material: steel mesh (welded wire, square opening per ISO 13857 limits), steel sheet (perforated for visibility or solid), polycarbonate sheet (for visibility — minimum 4 mm for light guarding, 8–12 mm for high-energy hazards)
Access Door Design
Access doors for inspection, maintenance, and material clearing are common design requirements for enclosed conveyor systems and process machinery. Key design considerations:
• Size: Minimum 600×600 mm for a person to reach through with both arms; full-entry access requires minimum 600×1800 mm or 700×1900 mm (ergonomic access opening per EN 547-2)
• Interlocking: Access doors that when opened would expose an operator to a running hazard must be interlocked (safety switch per ISO 14119 category per EN ISO 13849-1 PLc or higher depending on risk assessment). Hinge-mounted safety switches (e.g., Sick RE11, Schmersal AZ 200 series) are standard industrial solutions
• Hinges and latching: Heavy doors (>15 kg) require gas strut assistance to prevent slam hazard. Latching should be single-point to allow quick opening without tools (if interlocked) or multi-point industrial latch for high-vibration environments
• Captive fasteners: For removable panels, use captive screws (Southco, Dzus, Elesa quarter-turn fasteners) to prevent dropped fasteners into machinery
Maintenance Access Planning
Design maintenance access from the start, not as an afterthought. Minimum clearances for maintenance tasks:
• Bearing replacement: 500 mm clear space in the extraction direction; 300 mm radial clearance around bearing housing
• Belt tensioning: 600 mm clear behind tail pulley end for screw take-up adjustment
• Gearbox oil change: drain point accessible from below or side with drain pan space; sight glass or dip stick accessible without crawling under equipment
• Filter replacement: components accessible without removing adjacent equipment
Conclusion
Plant equipment design requires integrating structural adequacy, functional performance (conveyor belt selection and tensioning), and mandatory safety compliance (ISO 13857 safety distances, ISO 14120 guard construction, ISO 14119 interlocking) from the earliest design stages. The safety standards are not optional — machinery placed on the EU market must meet the Machinery Directive requirements, and similar regulatory frameworks apply in all major markets. Building guard design and maintenance access planning into the initial layout avoids the expensive retrofits that result from treating them as afterthoughts.
