Introduction
Bolted joints dominate mechanical assemblies for good reasons: they are reversible, adjustable, and well-understood. But experienced designers know that bolts are not always the best answer. Adhesives, press fits, and interference fits each offer specific advantages that bolts cannot match—and in certain applications, they are simply the correct engineering choice.
This article examines when and how to use these three alternative joining methods, with practical design guidance derived from field experience. Understanding the trade-offs between reversibility, load distribution, precision, and process complexity allows designers to select the optimal joining method for each interface in their assembly.
Structural Adhesives
When Adhesives Are the Right Choice
Structural adhesives—epoxies, acrylics, polyurethanes, and anaerobic adhesives—distribute load uniformly across the entire bonded area rather than concentrating it at fastener locations. This makes them superior for thin-walled structures, dissimilar materials, and applications where stress concentrations from drilled holes would be unacceptable.
Adhesives are particularly well-suited for: bonding lightweight thin sheet metal where drilling would weaken the part; attaching inserts or brackets to composite or plastic components where threads would strip; sealing and joining simultaneously in electronics enclosures; and assembling components where external fastener heads would impair function or aesthetics.
Key Design Considerations
Adhesive joints are strong in shear but weak in peel and tension perpendicular to the bond line. Design the joint geometry to keep the adhesive in shear as much as possible. Lap joints, scarf joints, and strap joints all perform significantly better than butt joints in structural applications.
Surface preparation is critical—typically more important than adhesive selection. Contamination with oils, moisture, or release agents will cause adhesive failure regardless of product specification. Define surface preparation on the drawing: degrease with specified solvent, abrade to specified roughness, prime if required. Do not leave surface preparation to the assembler’s judgment.
Bond line thickness must be controlled. Most structural adhesives achieve maximum strength at a bond line of 0.1–0.5 mm. Using shims or adhesive beads to maintain uniform gap is good practice for critical joints.
Anaerobic Adhesives and Thread-Locking
Anaerobic adhesives (threadlockers, retaining compounds, pipe sealants) cure in the absence of oxygen and in the presence of metal ions. Threadlockers prevent fastener loosening under vibration without adding torque requirements or locking hardware. Retaining compounds fill the clearance between shaft and hub, creating a chemical interference fit that supplements or replaces mechanical interference. Always specify the strength grade: removable (low strength), medium strength for most applications, and high strength (requires heat to disassemble) for permanent joints.
Press Fits
Mechanism and Applications
A press fit (also called a force fit) uses elastic deformation to create a joint. The shaft diameter is slightly larger than the hole diameter, so axial force is required to assemble them. The resulting radial pressure between surfaces generates friction that resists axial and torsional loads.
Press fits are used for: bearing mounting (light press fit prevents fretting corrosion under vibration); gear-to-shaft connections where keys would add stress concentration; dowel pins for precise locating; and bushing installation where the bushing must not rotate relative to the housing.
Calculating Press Fit Parameters
The Lamé equations for thick-walled cylinders govern press fit behavior. The key parameter is interference—the difference between shaft diameter and hole diameter before assembly. Required interference depends on the torque or axial load to be transmitted, surface finish, and material properties (modulus of elasticity, Poisson’s ratio).
For a simplified estimate of transmittable torque from a press fit:
T = µ × p × π × d² × L / 2
where µ is the coefficient of friction, p is the contact pressure (calculated from interference and material properties), d is the nominal diameter, and L is the engagement length. Use µ = 0.1–0.15 for steel-on-steel press fits without lubrication. Always add a safety factor of at least 2.
Assembly Considerations
Press fits require controlled assembly force and are sensitive to surface finish and cleanliness. Scratch or burr on the mating surface during assembly creates a metal shaving that can jam or damage the bore. Always chamfer leading edges and clean surfaces before assembly. For large interference fits, thermal expansion (heating the hub or cooling the shaft) dramatically reduces assembly force and prevents galling.
Interference Fits (Shrink Fits)
How Interference Fits Differ from Press Fits
The distinction in ISO and ANSI standards between press fits and interference fits is sometimes treated as a matter of degree, but engineering practice treats them differently. A press fit is assembled by applying axial force at room temperature. An interference (shrink) fit achieves assembly by thermal differential—heating the hub to expand it, inserting the shaft, and allowing the joint to cool to room temperature. The resulting interference is identical mechanically, but the assembly process differs and larger interference values are practical.
Design Guidelines
Interference fits are specified through standardized fit tolerances (ISO standard fits: H7/p6, H7/r6, H7/s6, H7/u6 for increasing interference levels). Select the fit class based on required load capacity and whether disassembly is ever anticipated. H7/p6 (light drive) can be disassembled with specialized tooling; H7/u6 (force fit) is essentially permanent without heat or extreme force.
Always calculate maximum and minimum contact pressure over the tolerance range. The minimum contact pressure must exceed zero (joint must not slip under maximum load); the maximum contact pressure must not cause yielding in the hub or shaft under any tolerance combination. Thin-walled hubs are particularly vulnerable to yielding under high interference.
Comparison and Selection Guide
| Method | Load Type | Reversibility | Precision Requirement | Best For |
|---|---|---|---|---|
| Structural adhesive | Shear (primarily) | Difficult to none | Low to medium | Thin walls, dissimilar materials, combined sealing |
| Anaerobic retaining compound | Shear + axial | With heat/solvent | Medium | Shaft-to-hub, bearing retention supplement |
| Press fit | Axial + torque | Yes (with tooling) | High | Bearings, bushings, dowels |
| Interference (shrink) fit | High axial + torque | Difficult | Very high | Gears, couplings, permanent hubs |
| Bolted joint | All directions | Yes (easy) | Low to medium | Adjustable, serviceable connections |
FAQ
Q: Can I use adhesive in combination with a press fit to increase joint strength?
A: Yes, and this is a well-established technique. An anaerobic retaining compound applied before pressing doubles or triples the effective torque capacity of a press fit joint. The adhesive fills surface asperities, increasing actual contact area, while also preventing fretting corrosion. This combination is specified by many major manufacturers for bearing-to-housing and gear-to-shaft joints.
Q: How do I specify a press fit on a drawing so the manufacturer understands the intent?
A: Use standard ISO or ANSI fit tolerances (e.g., H7/p6) applied to the nominal dimension. This defines both the hole and shaft tolerances precisely. Additionally, note the assembly method (room temperature press, or heat/chill to specified temperature) and the required assembly force range if process control is needed. Specifying only the final interference without indicating the assembly method can lead to manufacturing errors, especially for large-diameter fits.
Q: Our product must be field-serviceable. Can we use interference fits for parts that need replacement?
A: Interference fits can be designed for field replacement if the correct tooling is available and the interference is not excessive. Light drive fits (H7/p6) can typically be removed with a hydraulic press or puller. For field serviceability, document the removal tooling requirements in the service manual, and confirm the hub can withstand repeated assembly/disassembly cycles without dimensional degradation. If service intervals are frequent, a keyed clearance fit or bolted split hub may be more appropriate.
