Why Surface Treatment Is a Design Decision, Not an Afterthought
Surface treatments are frequently specified by copying the previous drawing, using the plant default, or asking the purchasing department what is available. This approach produces inconsistent results and occasional failures — corrosion in unexpected environments, adhesion failures, dimensional non-conformances, or unexpected costs when the specified process is no longer available.
Surface treatment selection is a design decision with functional consequences. The correct process depends on the substrate material, the service environment, the functional requirements (hardness, conductivity, lubricity, appearance), and the dimensional impact of the treatment. This article provides a systematic framework for making that selection.
The Functions of Surface Treatments
Before selecting a treatment, clarify what it must do. Surface treatments serve multiple functions, and the priority determines the correct choice:
- Corrosion protection: create a barrier or electrochemically protective layer between the substrate and the corrosive environment
- Wear and hardness improvement: increase surface hardness to resist abrasive or adhesive wear
- Dimensional change: add material (build-up plating) or remove compliance (hard anodizing changes dimensions)
- Electrical properties: improve conductivity (silver, gold plating) or provide insulation (anodizing)
- Lubricity: reduce friction (PTFE impregnation, dry film lubricant coatings)
- Aesthetics: controlled appearance for customer-visible surfaces
Common Processes and Their Characteristics
Electroplating
Electroplating deposits a metal layer (zinc, nickel, chrome, tin, copper, silver, gold) onto a conductive substrate by electrochemical deposition. The plating thickness is controllable and typically ranges from 5–25 µm for protective zinc plating to 0.5–5 µm for precious metal contacts.
Zinc electroplating followed by chromate conversion coating is the most cost-effective corrosion protection for steel fasteners and brackets in mild environments. Hexavalent chromate provides higher corrosion resistance but is restricted by RoHS and REACH in many applications; trivalent chromate is the standard alternative.
Hard chrome plating (0.025–0.25 mm thick) provides exceptional hardness (Vickers 900–1100) and wear resistance for hydraulic cylinder rods, tooling, and sliding guides. Dimensional impact must be accounted for in design: hard chrome plating of a shaft requires planning for the plating buildup in the tolerance specification.
Electroless Nickel Plating
Unlike electrolytic plating, electroless nickel deposits a uniform thickness regardless of part geometry — on internal bores, recesses, and complex shapes that electroplating deposits unevenly. The hardness as-plated is approximately Vickers 500; after heat treatment at 400 °C, it increases to Vickers 900–1000. Dimensional buildup is predictable at typically 25 µm total (12.5 µm per side).
Electroless nickel is the preferred treatment for precision components requiring both corrosion protection and dimensional uniformity.
Anodizing (Aluminum)
Anodizing converts the aluminum surface to aluminum oxide (alumina) by electrochemical oxidation. Type II (sulfuric acid) anodizing produces a 5–25 µm layer that provides moderate corrosion protection and is suitable for dyeing. Type III (hard anodizing) produces a 25–75 µm layer with hardness up to Vickers 500 and excellent wear resistance.
The dimensional impact of anodizing is approximately 50% outward growth, 50% inward penetration — a 25 µm Type III coating adds approximately 12.5 µm per external surface dimension. Holes and bores close by approximately the full coating thickness per side. Design to leave the anodizing allowance in the pre-treatment machined dimensions.
Painting and Powder Coating
Liquid paint and powder coating provide cost-effective corrosion protection for structural steel, weldments, and large fabrications where plating is impractical. Powder coating provides a harder, more impact-resistant finish than most liquid paints and is environmentally preferable (no solvent emissions).
Key variables for paint system selection: surface preparation (sandblasting grade, phosphate pretreatment), primer specification, topcoat specification, and expected coating thickness. Inadequate surface preparation is the leading cause of paint system failure; the substrate specification matters as much as the coating specification.
Selection Guide by Application
| Application | Substrate | Recommended Treatment | Notes |
|---|---|---|---|
| Steel fasteners, mild environment | Steel | Zinc electroplate + trivalent chromate | Salt spray 120–200 h |
| Steel structure, outdoor | Steel | Sandblast Sa2.5 + zinc primer + polyurethane topcoat | Marine environment: zinc silicate primer |
| Aluminum enclosure, architectural | Aluminum | Type II anodize (clear or colored) | Allow 0.01–0.025 mm per surface for coating |
| Aluminum wear surface | Aluminum | Type III hard anodize | Allow 0.025–0.075 mm per surface |
| Precision bore, corrosion + wear | Steel or aluminum | Electroless nickel (EN) | Uniform buildup; specify pre-plating dimensions |
| Hydraulic cylinder rod | Steel | Hard chrome or thermal spray + grind | Hard chrome: RoHS compliance check required |
| Electrical contacts | Copper or brass | Gold or silver plate over nickel barrier | Nickel barrier prevents diffusion |
Specifying Treatments on Drawings
A surface treatment callout must specify: the process name (with standard reference if applicable), the coating thickness range, post-treatment operations (grinding, stripping in thread areas, masking), and the inspection method or acceptance criterion. Incomplete callouts — “zinc plated” without specifying thickness, passivation type, or salt spray requirement — produce inconsistent results across suppliers.
FAQ
Q: I need corrosion protection on a stainless steel component. What should I specify?
Most stainless steel grades (304, 316) provide good corrosion resistance through their native chromium oxide passive layer. The treatment required is proper passivation (per ASTM A967 or AMS 2700) after machining to remove free iron contamination from tooling. Additional plating or coating on stainless is rarely needed for normal environments; for marine or highly acidic service, evaluate whether the base material should be changed to a higher-grade alloy rather than relying on a coating.
Q: Can I specify hard anodizing on aluminum threads?
Hard anodizing on threaded features is problematic: the coating grows into the thread profile, changing the effective pitch diameter and potentially seizing mating threads. Standard practice is to mask threads before anodizing or to tap threads after anodizing to re-establish the correct dimension. Specify masking requirements and post-anodize thread correction explicitly on the drawing.
Q: Our supplier says the hard chrome we specified is prohibited. What are the alternatives?
Hexavalent chromium (Cr6+) used in hard chrome plating is restricted under REACH and other regulations. Alternatives include: trivalent chrome (Cr3+) plating, which provides lower hardness; electroless nickel with heat treatment; thermal spray coatings (tungsten carbide, chrome oxide) applied by HVOF; and physical vapor deposition (PVD) coatings for high-precision applications. The correct alternative depends on the functional requirements — hardness, coating thickness, dimensional precision, and adhesion strength differ between processes.
